Xerox WorkCentre 5225 Service Manual

February, 2008
2-144
WorkCentre 5225, 5230
012-300
Launch Version
Status Indicator Raps
012-300 Eject Cover Open
BSD-ON:12.12
Eject Cover Switch open was detected.
Initial Actions
• Ensure that the Eject Cover is down
• Check Eject Cover Switch for improper installation
• Check Eject Cover Switch connectors for connection failure
• Check Actuator part for deformation
Procedure
Enter Component Control [012-300], Eject Cover Switch (PL 23.11). Select Start. Actuate the
Eject Cover Switch.
The display changes
YN
Select Stop. Check continuity of the Eject Cover Switch. The continuity check is OK.
YN
Replace the Eject Cover Switch (PL 23.11).
Check continuity between the Eject Cover Switch and the Finisher PWB. If the check is
OK, replace the Finisher PWB (PL 23.16).
Select Stop. If the problem continues, replace the Finisher PWB (PL 23.16).
