Xerox WorkCentre 5225 Service Manual

February, 2008
2-315
WorkCentre 5225, 5230
024-930 (A-Finisher)
Status Indicator Raps
Launch Version
Measure the voltage between J8708-2 (+) on the Finisher PWB and GND (-). Block and
unblock the Stack Height Sensor with a piece of paper.
The voltage changes.
YN
Replace the Stack Height Sensor (PL 22.10).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Run DC330[012-278].
Enter [012-278]. Rotate the Stacker Stack Sensor 1 actuator by hand to block and unblock the
sensor.
The display changes.
YN
Check the connections of P/J8707 and P/J8722. P/J8707 and P/J8722 are securely
connected.
YN
Connect P/J8707 and P/J8722 securely.
Check for an open or short circuit between J8707 and J8722. The wires between
J8707 and J8722 are OK.
YN
Repair the open or short circuit.
Measure the voltage between J8707-6 (+) on the Finisher PWB and GND (-). The volt-
age is approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
Measure the voltage between J8707-5 (+) on the Finisher PWB and GND (-). Rotate the
Stacker Stack Sensor 1 actuator by hand to block and unblock the sensor.
The voltage
changes.
YN
Replace the Stacker Stack Sensor 1 (PL 22.8).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Enter [012-279]. Rotate the Stacker Stack Sensor 2 actuator by hand to block and unblock the
sensor.
The display changes.
YN
Check the connections of P/J8707 and P/J8721. P/J8707 and P/J8721 are securely
connected.
YN
Connect P/J8707 and P/J8721 securely.
Check for an open or short circuit between J8707 and J8721. The wires between
J8707 and J8721 are OK.
YN
Repair the open or short circuit.
Measure the voltage between J8707-3 (+) on the Finisher PWB and GND (-). The volt-
age is approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
Measure the voltage between J8707-2 (+) on the Finisher PWB and GND (-). Rotate the
Stacker Stack Sensor 2 actuator by hand to block and unblock the sensor.
The voltage
changes.
YN
Replace the Stacker Stack Sensor 2 (PL 22.8).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Enter [012-060] and [012-061] alternately. The Stacker Motor rotates.
YN
Check the connections of P/J8711 and P/J8736. P/J8711 and P/J8736 are securely
connected.
YN
Connect P/J8711 and P/J8736 securely.
Check for an open or short circuit between J8711 and P8736. The wires between
J8711 and P8736 are OK.
YN
Repair the open or short circuit.
Enter [012-060], measure the voltage between J8711-1 (+) on the Finisher PWB and
GND (-).
The voltage changes.
YN
Replace the Finisher PWB (PL 22.7).
Enter [012-061], measure the voltage between J8711-2 (+) on the Finisher PWB and
GND (-).
The voltage changes.
YN
Check the wires and connectors for an intermittent open or short circuit. If the prob-
lem continues, replace the Finisher PWB (PL 22.7).
Replace the Stacker Motor (PL 22.8).
Check the wires and connectors for an intermittent open or short circuit. If the problem contin-
ues, replace the Finisher PWB (PL 22.7).
A B
C
C
