February, 2008
2-376
WorkCentre 5225, 5230
024-989
Launch Version
Status Indicator Raps
024-989 Booklet Low Staple R
BSD-ON:12.27
Booklet Stapler Low Staple Rear signal was detected just before Stapling operation.
Booklet Stapler Low Staple Rear signal was detected at Power ON, at initialization, or when the
interlock was closed.
Procedure
Supply the staples. The problem is resolved.
YN
Enter Component Control [013-108 Rear Low Staple Switch]. Select Start. ‘LOW’ (sta-
ples available) is displayed
YN
Check the connections of J8894, P/J8995 and P/J8892. The connectors are
connected correctly.
YN
Connect the connectors.
Check the wire between J8895 and J8995 for an open circuit or a short circuit (BSD
12.27).
The wire between J8895 and J8995 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8995-14 (+) and GND (-) (BSD
12.27).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8895-1 (+) and GND (-) (BSD
12.27).
The voltage is approx. +5VDC.
YN
Replace the Rear Low Staple Switch (PL 23.20).
Replace the Finisher PWB (PL 23.16).
Select Stop. Replace the Finisher PWB (PL 23.16). If the problem continues, replace the
Booklet PWB (PL 23.21).
If the problem continues, replace the Finisher PWB (PL 23.16). If the problem persists, replace
the Booklet PWB (PL 23.21).
To Next Page
