Xilinx SelectIO 7 Series User Manual

7 Series FPGAs SelectIO Resources User Guide www.xilinx.com 101
UG471 (v1.10) May 8, 2018
Rules for Combining I/O Standards in the Same Bank
Table 1-56, summarizes the DRIVE and SLEW attribute options, bidirectional buffer
availability, and DCI termination type for each 7 series FPGA supported I/O standard.
Table 1-56: DRIVE and SLEW Attributes, Bidirectional Buffers, and DCI Termination Type
I/O Standard
I/O Bank
Availability
DRIVE (mA) SLEW
Bidirectional
Buffers
(1)
DCI Type
(2)
Outputs Outputs Outputs Inputs
BLVDS_25 HR N/A N/A Yes None None
DIFF_HSTL_I Both N/A SLOW, FAST No None None
DIFF_HSTL_I_18 Both N/A SLOW, FAST No None None
DIFF_HSTL_I_DCI HP N/A SLOW, FAST No None Split
DIFF_HSTL_I_DCI_18 HP N/A SLOW, FAST No None Split
DIFF_HSTL_II Both N/A SLOW, FAST Yes None None
DIFF_HSTL_II_18 Both N/A SLOW, FAST Yes None None
DIFF_HSTL_II_DCI HP N/A SLOW, FAST Yes Split Split
DIFF_HSTL_II_DCI_18 HP N/A SLOW, FAST Yes Split Split
DIFF_HSTL_II_T_DCI HP N/A SLOW, FAST Required None Split
DIFF_HSTL_II_T_DCI_18 HP N/A SLOW, FAST Required None Split
DIFF_HSUL_12 Both N/A SLOW, FAST Yes None None
DIFF_HSUL_12_DCI HP N/A SLOW, FAST Yes Driver None
DIFF_MOBILE_DDR HR N/A SLOW, FAST Yes None None
DIFF_SSTL12 HP N/A SLOW, FAST Yes None None
DIFF_SSTL12_DCI HP N/A SLOW, FAST No None Split
DIFF_SSTL12_T_DCI HP N/A SLOW, FAST Required None Split
DIFF_SSTL135 Both N/A SLOW, FAST Yes None None
DIFF_SSTL135_R HR N/A SLOW, FAST Yes None None
DIFF_SSTL135_DCI HP N/A SLOW, FAST No None Split
DIFF_SSTL135_T_DCI HP N/A SLOW, FAST Required None Split
DIFF_SSTL15 Both N/A SLOW, FAST Yes None None
DIFF_SSTL15_R HR N/A SLOW, FAST Yes None None
DIFF_SSTL15_DCI HP N/A SLOW, FAST No None Split
DIFF_SSTL15_T_DCI HP N/A SLOW, FAST Required None Split
DIFF_SSTL18_I Both N/A SLOW, FAST No None None
DIFF_SSTL18_I_DCI HP N/A SLOW, FAST No None Split
DIFF_SSTL18_II Both N/A SLOW, FAST Yes None None
DIFF_SSTL18_II_DCI HP N/A SLOW, FAST Yes Split Split
DIFF_SSTL18_II_T_DCI HP N/A SLOW, FAST Required None Split
