4-7
FUEL
E
4
4
Order Job/Part Q’ty Remarks
8 Throttle joint link rod 1
9 Nut 1
10 Collar 1
11 Wave washer 1
12 Washer 1
13 Accelerator cam 1
14 Stud bolt 1
For installation, reverse the removal
procedure.
7
12
11
13
14
10
8
9
5
6
4
3
1
2
6 × 30 mm
LTLT
SS
LTLT
SS
4020
CONTROL UNIT
