6-11
E
LOWR
PROPELLER SHAFT HOUSING ASSEMBLY
(REGULAR ROTATION MODELS)
6
DISASSEMBLING/ASSEMBLING THE PROPELLER SHAFT HOUSING
6
Order Job/Part Q’ty Remarks
1 O-ring 1
2 Reverse gear 1
3 Thrust washer 1
4 Ball bearing 1
5 Oil seal 2
6 Needle bearing 1
7 Propeller shaft housing 1
For assembly, reverse the disassembly
procedure.
6090
