Yamaha F115A - Shimming (Counter Rotation Models) (for Usa and Canada)

6-70
E
LOWR
SHIMMING (COUNTER ROTATION MODELS) (FOR USA AND CANADA) 6
NOTE:
• There is no need to select shims when
reassembling with the original case and
inner parts.
• Shim calculations are required when reas-
sembling with the original inner parts and
a new case (the difference between the
original inner parts and the new case).
• Measurements and adjustments are
required when replacing the inner part(s).
6A10
F
R
P
T3
B3
B4
59.0
A3
B2
T1 B133.3 T2 T4
A1
15.1
A2
SHIMMING (COUNTER ROTATION MODELS)
(FOR USA AND CANADA)
