LOWER UNIT (REGULAR ROTATION MODELS)
LOWER UNIT (REGULAR ROTATION MODELS)
6
REMOVING/INSTALLING THE LOWER UNIT 6
Order Job/Part Q’ty Remarks
1 Speedometer hose 1
2 Cotter pin 1
3 Propeller nut 1
4 Washer 1
5 Washer 1
6 Propeller 1
7 Spacer 1
Continued on next page.
14
13
8
9
1
7
2
3
4
5
6
10
12
11
43 Nm (4.3 m
•
kgf, 31 ft
•
Ib)
10 × 45 mm : 12 mm
55 Nm (5.5 m
•
kgf, 40 ft
•
Ib)
37 Nm (3.7 m
•
kgf, 27 ft
•
Ib)
10 × 70 mm
37 Nm (3.7 m
•
kgf, 27 ft
•
Ib)
10 × 45 mm
LTLT
LT
572
LTLT
LT
572
M
A
6010
