Yamaha F115A - Removing;Installing the Clamp Brackets

7-24
BRKT
E
CLAMP BRACKETS 7
REMOVING/INSTALLING THE CLAMP BRACKETS
Order Job/Part Q’ty Remarks
Upper case assembly Refer to “UPPER CASE ASSEMBLY” on
page 7-16.
1 Grease nipple 4
2 Ground lead 1
3 Bolt 4
4 Ground lead 1
5 Anode bracket 2
6 Anode 1
7 Trim sensor 1
8 Self-locking nut 1
Continued on next page.
7100
CLAMP BRACKETS
