Yamaha F115A - THROTTLE POSITION SENSOR

4-24
FUEL
E
THROTTLE POSITION SENSOR
THROTTLE POSITION SENSOR
4
REMOVING/INSTALLING THE THROTTLE POSITION SENSOR
Order Job/Part Q’ty Remarks
1 Throttle position sensor
connector
1
2 Screw 2
3 Throttle position sensor 1
For installation, reverse the removal
procedure.
2
3
1
4190
