7-2

BRKT

REMOVING/INSTALLING THE STEERING HANDLE

Order Job/Part Q’ty Remarks

1 Bolt 2

2 Fitting plate 1

3 Clip 2

4 Throttle cable 1

5 Bolt 1

6 Cable clamp 1

7 Shift cable 1

8 Bolt 1

9 Plate 1

10 Bolt 1

Continued on next page.

7020

38 Nm (3.8 m • kgf, 27.5 ft • Ib)

STEERING HANDLE (OPTION)
