6-34
E
LOWR
PROPELLER SHAFT HOUSING ASSEMBLY
(COUNTER ROTATION MODELS)
PROPELLER SHAFT HOUSING ASSEMBLY
(COUNTER ROTATION MODELS)
6
REMOVING/INSTALLING THE PROPELLER SHAFT HOUSING ASSEMBLY 6
Order Job/Part Q’ty Remarks
Gear oil Refer to “CHANGING AND CHECKING
THE GEAR OIL” on page 3-18.
Shift rod assembly Refer to “SHIFT ROD ASSEMBLY
(COUNTER ROTATION MODELS)” on
page 6-32.
1 Ring nut 1
2 Claw washer 1
3 Propeller shaft housing assembly 1
Continued on next page.
6460
7
6
5
3
4
2
1
105 Nm (10.5 m • kgf, 76 ft • Ib)
A
To Next Page
