4-20
FUEL
E
IDLE SPEED CONTROL ASSEMBLY
4
4
Order Job/Part Q’ty Remarks
7 Vacuum hose 1 (idle speed control assembly-to-intake
manifold)
8 Hose 1 (idle speed control assembly-to-throttle
body #2)
9 Hose 1 (idle speed control assembly-to-throttle
body #1)
10 Idle speed control assembly 1
For installation, reverse the removal
procedure.
2
3
4
5
6
8
6
10
6
7
1
9
6
6 × 24 mm
6 × 60 mm
