Yamaha F115A - Page 268

5-37
POWR
E
CRANKSHAFT AND PISTON/
CONNECTING ROD ASSEMBLY
5
4
Order Job/Part Q’ty Remarks
8 Connecting rod bolt 8
9 Connecting rod cap 4
10 Crankshaft 1
11 Main bearing 5
12 Big end bearing 4
13 Piston/connecting rod assembly 4
14 Oil seal 1
15 Oil seal 1
16 Cylinder block 1
For installation, reverse the removal
procedure.
19 Nm (1.9 m • kgf, 14 ft • Ib)1st
60°
2nd
10 × 135 mm
14 Nm (1.4 m • kgf, 10 ft • Ib)1st
28 Nm (2.8 m • kgf, 20 ft • Ib)2nd
8 × 55 mm
15 Nm (1.5 m • kgf, 11 ft • Ib)1st
60°2nd
8 × 38 mm
E
E
E
E
E
6
7
1
2
3
4
5
15
13
a
8
12
14
16
10
9
GM
GM
11
11
11
11
11
E
E
50 Nm (5.0 m • kgf, 36 ft • Ib)*
8 Nm (0.8 m • kgf, 5.8 ft • Ib)
6 × 25 mm
5450
Not reusable
