Yamaha F115A - Page 304

6-2
E
LOWR
6
6
Order Job/Part Q’ty Remarks
8 Grommet 1
9 Bolt 1
10 Trim tab 1
11 Bolt 1 (with washer)
12 Bolt 6 (with washer)
13 Dowel pin 2
14 Lower unit 1
For installation, reverse the removal
procedure.
14
13
8
9
1
7
2
3
4
5
6
10
12
11
43 Nm (4.3 m
•
kgf, 31 ft
•
Ib)
10 × 45 mm : 12 mm
55 Nm (5.5 m
•
kgf, 40 ft
•
Ib)
37 Nm (3.7 m
•
kgf, 27 ft
•
Ib)
10 × 70 mm
37 Nm (3.7 m
•
kgf, 27 ft
•
Ib)
10 × 45 mm
LTLT
LT
572
LTLT
LT
572
M
A
6010
LOWER UNIT (REGULAR ROTATION MODELS)
