6-26
E
LOWR
LOWER UNIT (COUNTER ROTATION MODELS)
LOWER UNIT (COUNTER ROTATION MODELS)
6
REMOVING/INSTALLING THE LOWER UNIT 6
Order Job/Part Q’ty Remarks
1 Speedometer hose 1
2 Cotter pin 1
3 Propeller nut 1
4 Washer 1
5 Washer 1
6 Propeller 1
7 Spacer 1
Continued on next page.
6410
3
4
43 Nm (4.3 m • kgf, 31 ft • Ib)
55 Nm (5.5 m • kgf, 40 ft • Ib)
10 × 45 mm : 12 mm
5
2
43 Nm (4.3 m • kgf, 31 ft • Ib)
10 × 70 mm
37 Nm (3.7 m • kgf, 27 ft • Ib)
10 × 45 mm
12
11
10
6
7
9
8
13
14
1
M
A
LTLT
LT
572
LTLT
LT
572
