7-28
BRKT
E
7
Order Job/Part Q’ty Remarks
7 Starboard tilt stop lever 1
8 Port tilt stop lever 1
9 Bushing 2
10 Bushing 2
11 Tilt stop lever joint assembly 1
For assembly, reverse the disassembly
procedure.
7120
SWIVEL BRACKET ASSEMBLY
