7-30
BRKT
E
POWER TRIM AND TILT UNIT
7
Order Job/Part Q’ty Remarks
7 Bolt 2
8 Washer 2
9 Lower mounting pin 1
10 Power trim and tilt unit 1
11 Collar 6
For installation, reverse the removal
procedure.
7130
