7-32
E
BRKT
POWER TRIM AND TILT UNIT
(3) Tilt up the outboard fully, then release
it, and let it lower by its own weight.
(4) Tighten the manual valve by turning it
clockwise.
(5) Let the power trim and tilt fluid settle
for about 5 minutes.
(6) Push and hold the power trim and tilt
switch in the up position until the out-
board is fully tilted up.
(7) Turn the tilt stop levers to support the
outboard. Then, let the power trim and
tilt fluid settle for about 5 minutes.
(8) Remove the reservoir cap 2 and check
that fluid is up to the brim as shown.
Add fluid if the level is below the brim.
(9) Install the power trim and tilt reservoir
cap.
(10) Repeat the above steps two or three
times until the power trim and tilt fluid
is at the correct level.
7160
7170
