TIGHTENING TORQUES
BRACKET UNIT
Friction piece — 13 1.3 9.4
Steering handle assembly — 38 3.8 27.5
Main switch assembly — 5 0.5 3.7
Engine stop lanyard switch — 4 0.4 2.9
Shift lever M8 18 1.8 13
Steering handle bracket M10 38 3.8 27.5
Shift rod detent mechanism screw — 18 1.8 13
Oil pump M6 11 1.1 8.0
Upper mount M12 53 5.3 38
Lower mount M14 73 7.3 53
Muffler assembly M8 20 2.0 14
Exhaust manifold M6 11 1.1 8.0
Oil pan M6 11 1.1 8.0
Oil strainer M6 11 1.1 8.0
Clamp bracket M22 15 1.5 11
Cam — 2 0.2 1.4
Trim stopper — 37 3.7 27
POWER TRIM AND TILT UNIT
Power trim and tilt reservoir 1/4” 5 0.5 3.6
Power trim and tilt motor 1/4” 5 0.5 3.6
Manual valve — 4 0.4 2.9
Tilt ram end screw — 130 13 94
Gear pump unit 5/16” 9 0.9 6.5
Gear pump — 6 0.6 4.3
Trim ram end screw — 80 8.0 52
Part to be tightened Thread size
Tightening torques
Nm m•kgf ft•lb
