Yamaha F115A - Page 640

8-27
–+
ELEC
E
STARTER MOTOR
8
8
Order Job/Part Q’ty Remarks
20 Shift lever 1
21 Outer ring gear 1
22 Planetary gear 3
23 E-ring 1
24 Pinion shaft 1
25 Center bracket 1
26 Thrust washer 1
27 Clutch assembly 1
28 Bearing 1
29 Housing 1
For assembly, reverse the disassembly
procedure.
3
1
5
20
29
25
4
24
22
21
2
28
27
23
26
8
6
7
19
18
12
17
16
15
13
14
11
10
4 × 14 mm
6 × 120 mm
6 × 52 mm
9
A
A
A
8380
