YASKAWA E-7S SERVOPACK SGD7S - Page 185

5.12 Motor Stopping Methods for Servo OFF and Alarms
5.12.2 Servomotor Stopping Method for Alarms
5-37
5
Basic Functions That Require Setting before Operation
Note: 1. The setting of Pn00A is ignored if Pn00B is set to n.0 or n.1.
2. Refer to the following section for details on Pn406 (Emergency Stop Torque).
Stopping the Servomotor by Setting Emergency Stop Torque on page 5-37
3. Refer to the following section for details on Pn30A (Deceleration Time for Servo OFF and Forced Stops).
Stopping the Servomotor by Setting the Deceleration Time on page 5-38
Stopping the Servomotor by Setting Emergency Stop
Torqu e
To stop the Servomotor by setting emergency stop torque, set Pn406 (Emergency Stop
Torque).
If Pn00A = n.X is set to 1 or 2, the Servomotor will be decelerated to a stop using the
torque set in Pn406 as the maximum torque.
The default setting is 800%. This setting is large enough to allow you to operate the Servomo-
tor at the maximum torque. However, the maximum emergency stop torque that you can actu-
ally use is the maximum torque of the Servomotor.
* Set a percentage of the motor rated torque.
Parameter
Servomotor
Stopping Method
Status after
Servomotor
Stops
When
Enabled
Classification
Pn00B Pn00A Pn001
n.
0
(default
setting)
–
n.
0
(default setting)
Zero-speed stop-
ping
Dynamic
brake
After restart Setup
n.
1
Coasting
n.2
n.
1 –
n.
0
(default setting)
Dynamic brake
Dynamic
brake
n.
1
Coasting
n.2 Coasting
n.
2
n.0
n.
0
(default setting)
Dynamic brake
Dynamic
brake
n.
1
Coasting
n.2 Coasting
n.
1
(default
setting)
n.
0
(default setting)
Motor is deceler-
ated using the
torque set in
Pn406 as the
maximum torque.
Dynamic
brake
n.
1
Coasting
n.2
n.
2
n.
0
(default setting)
Coasting
n.1
n.2
n.
3
n.
0
(default setting)
Motor is deceler-
ated according to
setting of Pn30A.
Dynamic
brake
n.
1
Coasting
n.2
n.
4
n.
0
(default setting)
Coasting
n.1
n.2
Pn406
Emergency Stop Torque
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 800 1%* 800 Immediately Setup
