8.9 Anti-Resonance Control Adjustment
8.9.4 Operating Procedure
8-51
2.
Click the Anti-res Ctrl Adj Button.
The rest of the procedure depends on whether you know the vibration frequency.
3.
If you do not know the vibration frequency, click the Auto Detect Button. If you know the
vibration frequency, click the Manual Set Button.
4.
Click the Start adjustment Button.
5.
Use the and Buttons in the Adjustment Area to change the settings.
Click the Reset Button during tuning to restore the setting to its original value. The tuning level will
return to the value from before when custom tuning was started.
To Automatically Detect the Vibration
Frequency
The frequency will be set.
To Manually Set the Vibration Frequency
To Automatically Detect the Vibration
Frequency
Change the setting of the damping gain.
To Manually Set the Vibration Frequency
Change the settings of the frequency and
damping gain.
To Next Page
