13.5 ZONE Outputs
13.5.4 ZONE Output Application Example
13-63
13
Operation with Digital I/O
Using the ZONE Outputs as Passing Signals
In this example, the ZONE numbers are output at passing signals as the motor passed through
the registered zones. You can use the passing signals as required, e.g., to trigger operations
related to positioning.
Assume that the program table consists of the following two steps.
The ZONE table is shown below.
PGMSTEP POS SPD RDST RSPD ACC DEC POUT EVENT LOOP NEXT
0 A+500000 30000 - 1000 : : NNNZZZZZ IT0 1 1
1 A+000000 30000 - 1000 : : NNNZZZZZ IT0 1 0
ZONE Number
(ID)
ZONE N ZONE P
000
1 +99995 +100004
2 +199995 +200004
300
4 +299995 +300004
500
600
700
8 +399995 +400004
900
10 0 0
11 0 0
12 0 0
13 0 0
14 0 0
15 0 0
16 +499995 +500004
17 0 0
18 0 0
19 0 0
20 0 0
21 0 0
22 0 0
23 0 0
24 0 0
25 0 0
26 0 0
27 0 0
28 0 0
29 0 0
30 0 0
31 0 0
