14.8 Serial Commands
14.8.7 Editing Parameters, Monitoring, and Utility Functions
14-35
14
Operation with Serial Command Communications
STS or MON6 Status Flag Monitor
STS = 1010101 [CR] [LF]
Bit 0: ON (1) when the /INPOSITION
(positioning completed) signal
is active.
Bit 1: ON (1) when the NEAR (near
position) signal is active.
Bit 2: ON (1) when the DEN (posi-
tioning reference distribution
completed) signal is active.
Bit 3: ON (1) when positioning or
program operation is inter-
rupted (on hold).
Bit 4: ON (1) during program opera-
tion.
Bit 5: ON (1) when the current
(torque) is being limited.
Bit 6: ON (1) when the main power
supply is ON.
PUN or MON1*
Position Reference Current Position PUN = +12345678 [CR] [LF]
PFB or MON7*
Current (Actual) Motor Position Monitor PFB = +12345678 [CR] [LF]
POS or MON8*
Target Position Monitor POS = +12345678 [CR] [LF]
DST or MON9*
Target Distance Monitor DST = +12345678 [CR] [LF]
RPOS or MON10*
Registration Target Position Monitor RPOS = +12345678 [CR] [LF]
RDST or MON11*
Registration Target Distance Monitor RDST = 12345678 [CR] [LF]
NFB or MON3
Motor Speed Monitor [min
-1
] (rotational
motor)
Motor Speed Monitor [mm/s] (linear motor)
NFB = +12345678 [CR] [LF]
TREF or MON5
Internal Torque Reference Monitor [%] TREF = +12345678 [CR] [LF]
NREF or MON4
Speed Reference Monitor [min
-1
] (rotational
motor)
Speed Reference Monitor [mm/s] (linear
motor)
NREF = 12345678 [CR] [LF]
PER or MON2*
Position Error Monitor [Reference units] PER = +12345678 [CR] [LF]
TRMS Cumulative Load Ratio Monitor [%] TRMS = 12345678 [CR] [LF]
RGRMS Regeneration Load Ratio Monitor [%] TGRMS = 12345678 [CR] [LF]
DBRMS Dynamic-Brake Load Ratio Monitor [%] DBRMS = 12345678 [CR] [LF]
HALLSENS Hall Sensor Monitor for Linear Servomotor
TYPE
INDEXER Module Model Code Display
INDEXER Module Model Code = 0A03
TYPE = 00000A03 [CR] [LF]
(Displayed in hexadecimal)
YSPEC
INDEXER Module Special Specification No.
Display
YSPEC = 12345678 [CR] [LF]
VER INDEXER Module Firmware Version Display
VER = 00001234 [CR] [LF]
(Displayed in hexadecimal)
SVTYPE
SERVOPACK Model Code Display
SGD7S-E0A = 73
SVTYPE = 00000073 [CR] [LF]
(Displayed in hexadecimal)
SVYSPEC
SERVOPACK Special Specification No. Dis-
play
SVYSPEC = 12345678 [CR] [LF]
SVVER SERVOPACK Firmware Version Display
SVVER = 12345678 [CR] [LF]
(Displayed in hexadecimal)
Continued on next page.
Continued from previous page.
Serial Command Function/Description Positive Response
HALLSENS=1[SP]LLH[CR][LF]
A number
between
0 and 7
Status of phase
W [H or L]
Status of phase
V [H or L]
Status of phase
U [H or L]
To Next Page
