15.4 Troubleshooting Based on the Operation and Conditions of the Servomotor
15-70
Servomotor
Does Not
Start
The safety input signals
(/HWBB1 or /HWBB2) were
not turned ON.
Check the /HWBB1 and
/HWBB2 input signals.
Turn ON the /HWBB1
and /HWBB2 input sig-
nals. If you are not
using the safety func-
tion, connect the Safety
Jumper Connector
(provided as an acces-
sory) to CN8.
page 9-6
A failure occurred in the SER-
VOPACK.
Turn OFF the power
supply to the servo
system.
Replace the SERVO-
PACK.
The polarity detection was
not executed.
Check the setting of
Pn080 =n.X (Polar-
ity Sensor Selection).
Correct the parameter
setting.
page 5-23
Check the /S-ON (Servo
ON) signal.
If you are using an
incremental linear
encoder, input the /S-
ON signal from the
host controller.
If you are using an
absolute linear
encoder, execute
polarity detection.
page 5-24
Servomotor
Moves
Instanta-
neously,
and Then
Stops
There is a mistake in the Ser-
vomotor wiring.
Turn OFF the power sup-
ply to the servo system.
Check the wiring.
Wire the Servomotor
correctly.
There is a mistake in the wir-
ing of the encoder or Serial
Converter Unit.
Turn OFF the power sup-
ply to the servo system.
Check the wiring.
Wire the Serial Con-
verter Unit correctly.
There is a mistake in the lin-
ear encoder wiring.
Turn OFF the power sup-
ply to the servo system.
Check the wiring.
Wire the cable cor-
rectly.
The setting of Pn282 (Linear
Encoder Pitch) is not correct.
Check the setting of
Pn282.
Correct the setting of
Pn282.
page 5-16
The count-up direction of the
linear encoder does not
match the forward direction
of the Moving Coil in the
motor.
Check the directions.
Change the setting of
Pn080 = n.X
(Motor Phase Selec-
tion). Place the linear
encoder and motor in
the same direction.
page 5-21
Polarity detection was not
performed correctly.
Check to see if electrical
angle 2 (electrical angle
from polarity origin) at any
position is between ±10°.
Correct the settings for
the polarity detection-
related parameters.
Servomotor
Speed Is
Unstable
There is a faulty connection
in the Servomotor wiring.
The connector connec-
tions for the power line
(U, V, and W phases) and
the encoder or Serial
Converter Unit may be
unstable.
Turn OFF the power sup-
ply to the servo system.
Check the wiring.
Tighten any loose ter-
minals or connectors
and correct the wiring.
Continued on next page.
Continued from previous page.
Problem Possible Cause Confirmation Correction Reference
