YOKOGAWA UP55A User Manual

18-38
IM 05P02C41-01EN
DisplayFunctionSettingMenu(Menu:DISP)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
BDV
Bar-graph
deviation
display band
STD 0.0 to 100.0% of PV input range span (EUS)
1.0 % of PV
input range
span
EV1to
EV8
EV1 to EV8
display
condition
registration
PRO
Setting range: 4001 to 6304
OFF: Disable
4785: Link to PV event-1/local event-1 (Lit
when the event occurs)
4786: Link to PV event-2/local event-2 (Lit
when the event occurs)
4787: Link to PV event-3/local event-3 (Lit
when the event occurs)
4789: Link to PV event-4/local event-4 (Lit
when the event occurs)
4790: Link to PV event-5/local event-5 (Lit
when the event occurs)
4791: Link to PV event-6/local event-6 (Lit
when the event occurs)
4793: Link to PV event-7/local event-7 (Lit
when the event occurs)
4794: Link to PV event-8/local event-8 (Lit
when the event occurs)
4817: Link to time event-1 (Lit when the event occurs)
4818: Link to time event-2 (Lit when the event occurs)
4819: Link to time event-3 (Lit when the event occurs)
4821: Link to time event-4 (Lit when the event occurs)
4822: Link to time event-5 (Lit when the event occurs)
4823: Link to time event-6 (Lit when the event occurs)
4825: Link to time event-7 (Lit when the event occurs)
4826: Link to time event-8 (Lit when the event occurs)
4833: Link to time event-9 (Lit when the event occurs)
4834: Link to time event-10 (Lit when the event occurs)
4835: Link to time event-11 (Lit when the event occurs)
4837: Link to time event-12 (Lit when the event occurs)
4838: Link to time event-13 (Lit when the event occurs)
4839: Link to time event-14 (Lit when the event occurs)
4841: Link to time event-15 (Lit when the event occurs)
4842: Link to time event-16 (Lit when the event occurs)
4321: Link to alarm-1 (Lit when the alarm occurs)
4322: Link to alarm-2 (Lit when the alarm occurs)
4323: Link to alarm-3 (Lit when the alarm occurs)
4325: Link to alarm-4 (Lit when the alarm occurs)
4326: Link to alarm-5 (Lit when the alarm occurs)
4327: Link to alarm-6 (Lit when the alarm occurs)
4329: Link to alarm-7 (Lit when the alarm occurs)
4330: Link to alarm-8 (Lit when the alarm occurs)
4529: Heater break alarm 1 (Lit when the alarm occurs)
4530: Heater break alarm 2 (Lit when the alarm occurs)
* For other functions, see the UTAdvanced Series
Communication Interface User’s Manual.
EV1: 4785
EV2: 4786
EV3: 4787
EV4: 4789
EV5: 4790
EV6: 4791
EV7: 4793
EV8: 4794
In Cascade control, the following parameters are also displayed for secondary loop. (the LP2 lamp
is lit)
• Parameter: BDV, EV1 to EV8
18.2ListofParameters
