Parameters
18
DisplayFunctionSettingMenu(Menu:DISP)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
EV1to
EV8
EV1 to EV8
display
condition
registration
PRO
Setting range: 4001 to 6304
OFF: Disable
5025 to 5027: Link to DI1-DI3 (Lit when the
contact is closed)
5041 to 5046: Link to DI11-DI16 (E1-terminal
area) (Lit when the contact is closed)
5057 to 5062: Link to DI21-DI26 (E2-terminal
area) (Lit when the contact is closed)
5073 to 5077: Link to DI31-DI35 (E3-terminal
area) (Lit when the contact is closed)
5089 to 5094: Link to DI41-DI46 (E4-terminal
area) (Lit when the contact is closed)
5153 to 5155: Link to AL1-AL3 (Lit when the
contact is closed)
5169 to 5173: Link to DO11-DO15 (E1-
terminal area) (Lit when the contact is
closed)
5185 to 5189: Link to DO21-DO25 (E2-
terminal area) (Lit when the contact is
closed)
5201 to 5205: Link to DO31-DO35 (E3-
terminal area) (Lit when the contact is
closed)
5217 to 5221: Link to DO41-DO45 (E4-
terminal area) (Lit when the contact is
closed)
* For other functions, see the UTAdvanced
Series Communication Interface User’s
Manual.
EV1: 4785
EV2: 4786
EV3: 4787
EV4: 4789
EV5: 4790
EV6: 4791
EV7: 4793
EV8: 4794
In Cascade control, the following parameters are also displayed for secondary loop. (the LP2 lamp
is lit)
• Parameter: EV1 to EV8
18.2ListofParameters
