YOKOGAWA UP55A User Manual

18-40
IM 05P02C41-01EN
DisplayFunctionSettingMenu(Menu:DISP)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange
Initial
value
PV.D
PV display area
ON/OFF
PRO
OFF: Nondisplay, ON: Display
ON
SP.D
Setpoint display
area ON/OFF
PRO ON
STS.D
Status display
area ON/OFF
PRO ON
SPD Scroll speed PRO (Slow) 1 to 8 (Quick) 4
GUID
Guide display ON/
OFF
STD
OFF: Nondisplay
ON: Display
ON
HOME
Home Operation
Display setting
PRO
SP1: SP Display
SP2: Loop-2 SP Display
OUT1: OUT Display
OUT2: Loop-2 OUT Display
HCO: Heating/cooling OUT Display
VP: Valve Position Display
MV: Position Proportional Computation Output
Display
PID1: PID Number Display
PID2: Loop-2 PID Number Display
HC1: Heater Break Alarm-1 Current Display
HC2: Heater Break Alarm-2 Current Display
PV1: PV2/PV1 Display
PV2: PV1/PV2 Display
PV: PV Analog Input Display
RSP: RSP Analog Input Display
AIN2: AIN2 Analog Input Display
AIN4: AIN4 Analog Input Display
CS1 to CS5: SELECT Display 1 to 5
TSP1: TSP Display
TSP2: Loop-2 TSP Display
R.TIM: Remaining Segment-tim Display
SEG.N: Segment Number Dispaly
R.CYC: Remaining Repetition Display
PTN: Program Pattern Display
AL5.8.1: Alarm-5 to -8 Status Display
AL5.8.2: Loop-2 Alarm-5 to -8 Status Display
SP1
ECO Economy mode STD
OFF: Disable
1: Economy mode ON (All indications
except PV display OFF)
2: Economy mode ON (All indications OFF)
3: Brightness 10 % (All indications)
OFF
BRI Brightness EASY (Dark) 1 to 5 (Bright) 3
B.PVW
White brightness
adjustmentofPV
display
PRO
AdjuststhewhitebrightnessofPVdisplay.
(Dark) -4 to 4 (Bright)
0
B.PVR
Red brightness
adjustmentofPV
display
PRO
AdjuststheredbrightnessofPVdisplay.
(Dark) -4 to 4 (Bright)
0
B.SP
Brightness
adjustmentof
Setpoint display
PRO
AdjuststhebrightnessofSPdisplay.
(Dark) -4 to 4 (Bright)
0
B.BAR
Brightness
adjustmentofBar-
graph display
PRO
AdjuststhebrightnessofSPdisplay.
(Dark) -4 to 4 (Bright)
0
B.STS
Brightness
adjustmentof
Status indicator
PRO
AdjuststhebrightnessofStatusindicator.
(Dark) -4 to 4 (Bright)
0
D.CYC
Display update
cycle
PRO
1: 100 ms
2: 200 ms
3: 500 ms
4: 1 s
5: 2 s
2
18.2ListofParameters
