18-47
IM 05P02C41-01EN
Parameters
18
DISettingMenu(Menu:DI.D)(E1andE4terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
DI1.D DIn1 contact type PRO
0: The assigned function is
enabled when the contact input
is closed.
1: The assigned function is
enabled when the contact input
is opened.
0
DI2.D DIn2 contact type PRO 0
DI3.D DIn3 contact type PRO 0
DI4.D DIn4 contact type PRO 0
DI5.D DIn5 contact type PRO 0
n: Terminal area number (1, 3 or 4)
18.2ListofParameters
