18-48
IM 05P02C41-01EN
AL1-AL3FunctionRegistrationMenu(Menu:ALM)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
AL1.S
AL1 function
selection
STD
Set an I relay number.
Setting range: 4001 to 6304
No function: OFF
PV event 1: 4801, PV event 2: 4802,
PV event 3: 4803, PV event 4: 4805,
PV event 5: 4806, PV event 6: 4807,
PV event 7: 4809, PV event 8: 4810,
Time event 1: 4817,
Time event 2: 4818,
Time event 3: 4819,
Time event 4: 4821,
Time event 5: 4822,
Time event 6: 4823,
Time event 7: 4825,
Time event 8: 4826,
Time event 9: 4833,
Time event 10: 4834,
Time event 11: 4835,
Time event 12: 4837,
Time event 13: 4838,
Time event 14: 4839,
Time event 15: 4841,
Time event 16: 4842,
Alarm 1: 4353, Alarm 2: 4354,
Alarm 3: 4355, Alarm 4: 4357,
Alarm 5: 4358, Alarm 6: 4359,
Alarm 7: 4361, Alarm 8: 4362,
AUTO (OFF) / MAN (ON) status: 4177,
Program RESET status: 4181,
Program RUN status: 4182,
Local operation status: 4183,
Remote operation status: 4185,
HOLD mode status: 4189,
Program advance status: 4187,
Pattern end signal (1 second): 4265,
Pattern end signal (3 seconds): 4266,
Pattern end signal (5 seconds): 4267,
Wait end signal (1 second) : 4257,
Wait end signal (3 seconds) : 4258,
Wait end signal (5 seconds) : 4259,
Output tracking (ON) switching
signal: 4186,
FAIL (Normally ON) output: 4256
4801
AL2.S
AL2 function
selection
STD 4802
AL3.S
AL3 function
selection
STD 4803
OR.S
OUT relay function
selection
STD OFF
OR2.S
OUT2 relay function
selection
STD OFF
AL1.D AL1 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
0
AL2.D AL2 contact type PRO 0
AL3.D AL3 contact type PRO 0
OR.D
OUT relay contact
type
PRO 0
OR2.D
OUT2 relay contact
type
PRO 0
18.2ListofParameters
