YOKOGAWA UP55A User Manual

18-49
IM 05P02C41-01EN
Parameters
18
DOSettingMenu(Menu:DO)(E1toE4terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
DO1.S
DOn1 function
selection
STD
Same as AL1.S.
DO11=4805, DO12=4806,
DO13=4807, DO14=4809,
DO15=4810,
DO21=4817, DO22=4818,
DO23=4819, DO24=4821,
DO25=4822
DO31=4823, DO32=4825,
DO33=4826, DO34=4833,
DO35=4834
DO41=OFF, DO42=OFF,
DO43=OFF, DO44=OFF,
DO45=OFF
See left
DO2.S
DOn2 function
selection
STD See left
DO3.S
DOn3 function
selection
STD See left
DO4.S
DOn4 function
selection
STD See left
DO5.S
DOn5 function
selection
STD See left
DO1.D DOn1 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
0
DO2.D DOn2 contact type PRO 0
DO3.D DOn3 contact type PRO 0
DO4.D DOn4 contact type PRO 0
DO5.D DOn5 contact type PRO 0
n: Terminal area number (1 to 4)
I/ODisplayMenu(Menu:I/O)
Parameter
symbol
Name
Display
level
Readonly
KEY Key status PRO
See Chapter 13.
X000 DI1-DI3 status (equipped as standard) PRO
X100 DI11-DI16 status (E1-terminal area) PRO
X200 DI21-DI26 status (E2-terminal area) PRO
X300 DI31-DI35 status (E3-terminal area) PRO
X400 DI41-DI46 status (E4-terminal area) PRO
Y000 AL1-AL3 status (equipped as standard) PRO
Y100 DO11-DO15 status (E1-terminal area) PRO
Y200 DO21-DO25 status (E2-terminal area) PRO
Y300 DO31-DO35 status (E3-terminal area) PRO
Y400 DO41-DO45 status (E4-terminal area) PRO
18.2ListofParameters
