nHardwareSpecications
DisplaySpecications
• PV display: 5-digit, 14-segment active color LCD (white/red)
Character height: 21.5 mm
• Data display: 5-digit, 11-segment color LCD (orange)
• Bar graph display: 12-segment color LCD (orange)
(1) PV display
(9) Deviation indicator
(2) Group display
(Pattern number)
(10) Status indicator
(11) Security indicator
(12) Ladder operation indicator
(13) Loop 2 indicator
(4) Data display
(2) + (3) + (4) : Setpoint display
(3) Symbol display
(5) Bar-graph display
(Event, alarm)
(6) Event indicator
(7) Key navigation indicator
(8) Parameter display level
indicator
Names of Display Parts
(4) Light-loader interface
(5) User function keys
(1) DISPLAY key
(2) PARAMETER key
(3) SET/ENTER key
Up/Down/Left/Right arrow keys
