Call logging (CL)
324
System functions and features as of R3.0
syd-0367/1.3 – R3.0 – 03.2013
8. 7. 3 Examples of the PC5 output on a stand-alone commu-
nication server
8. 7. 3. 1 Outgoing calls to the public network
A business call is set up with the public network using self dialling. The digit se-
quence 010 is therefore entered as the sort character. Least Cost Routing function is
deactivated.
Fig. 154 Outgoing call to the public network
Tab. 114 OCL output for an outgoing call to the public network
8. 7. 3. 2 Incoming calls from the public network
Answered calls
All answered calls have a call duration greater than 0. The Time and Date fields indi-
cate when the call was set up. The TTA field specifies the duration of the ringing
phase. The sort character is 321.
NO CC SC DATE TIME DURATION CHARGES METPUL EXCH
201 010 060798 10:20 00H14M05 1.00 00010 00101
ID1 ID2 DEST1 DEST2 TTA SEQ.NO. SERIAL NO.
01 6242111 6242111 0001
