Identification elements
104
System functions and features as of R3.0
syd-0367/1.3 – R3.0 – 03.2013
4. 7. 3 Incoming calls from the public network
User G on the public network calls user C on PINX 2 via PINX 1. He dials 055 555 55
54.
Fig. 41 Example 6: User G calls user C (excerpt from Fig. 35)
Tab. 30 Example 6: Creating and presenting user G’s CLIP number
Step CLIP number NPI TON Description
1 066 333 33 33 E.164 Unknown User G → Exchange → PINX 1
2 66 333 33 33 E.164 National PINX 1
• Prefix is truncated
•TON is set to national.
3 66 333 33 33 E.164 National PINX 1 → PINX 2
4 66 333 33 33 E.164 National PINX 2
• CLIP number is not altered.
5 0-066 333 33 33
1)
1)
In PINX 3’s trunk group configuration 066 666 60 is entered as the master number.
PINX 2 → User C
• Presentation on the system phone
