IF the fuse is NOT blown, verify with a multimeter the 24V between
X37-pin1 and X37-pin2 (A10 board side).
o
IF X37 24V is OK, verify the 3D sensor ON signal, driven by CCU:
5V between the X38-pin 1 and X38-pin 7(GND).
-
IF 5V is OK, verify cable X42-J99 (between the A10 board
and the 3D sensor): if faulty fix or replace it. If the LED H2
is still OFF, replace the 3D Power Sensor board A10
-
IF 5V is NOT OK, verify the integrity of the cable X38-X61
(between 3D Power Sensor board A10 and CCU board A11)
and the cable X9-X9 (between MCU board A1 and CCU
board A11)
➢
IF the X38-X61 or X9-X9 are NOT OK, fix or replace
them
➢
IF the X38-X61 or X9-X9 are OK, replace the MCU board
A1.
o
IF the X37 24V is NOT OK, disconnect the X37 connector (A10
board side) and verify if between X37-pin1 and X37-pin2 (cable
side), there are 24V.
-
IF X37 24V is now OK, replace the 3D Power Sensor board
A10
-
IF X37 24V is still NOT OK, verify the cable X11-X37 and
perform the 24V power supply verification (see paragraph
11.2.3)
c.
Activate the sensor logs (see paragraph 11.2.1.4) and perform an
acquisition in order to reproduce the error.
Contact Technical Service providing the following additional information:
-
Software logs
-
3D Sensor logs folder (see paragraph 11.2.1)
-
Ceph sensor logs
-
Last RAW files folder stored (see paragraph 11.2.1.5)
