Agilent Technologies 1100 Series Reference Manual

1100 Series FD Reference Manual 343
Index
A
A/D overflow, 94
accessory kit, 18
accessory kit parts, 216
accuracy of wavelength, 328
Agilent on internet, 341
algea, 139
analog output, 268
analog signal output, 286
APG remote interface, 287
B
battery
description, 268
location on FLM board, 160
safety information, 335
BCD board, 283
BCD/LAN board, 282
bench space, 15
boards
interface board (BCD/LAN), 282
location of connectors, 160
C
cable
connecting APG remote, 21
connecting CAN, 21
connecting GPIB, 21
connecting LAN, 21
connecting the ChemStation, 21
connecting the power, 21
overview and identification, 218
calibration sample, 110
CAN interface, 286
check of Raman band of water, 104
configuration switch
default settings, 290
description and factory settings, 290
control module
Analysis screens, 299
Config screens, 316
Control screens, 316
Error Log screen, 319
Firmware Update screens, 321
Info Log and EMF screen, 319
introduction to FLD screens, 4
Maintenance screens, 322
Method screens, 313
part numbers, 208
Records screen, 318
Run Times screen, 310
Settings screens, 301
Signal Pllot screens, 312
Spectrum screens, 306
Status screens, 310
System screen, 315
Tests and Diagnostic screens, 323
Timetable screens, 305
cut-off filter, 243
cutoff filter
other type, 215
cuvette, 238
how to use, 138
D
DAC test, 127
dark current test, 117
degradation UV, 115, 245
delivery checklist, 17
dimensions and weight, 16
dispersion of light, 247
E
early maintenance feedback (EMF), 259
electrical connections
description of, 256
EMF (early maintenance feedback), 259
emission condenser, 243
emission grating, 243
emission monochromator, 247
emission slit, 243
environment, 15
error messages, 77
A/D overflow, 94
ADC not calibrated, 93
compensation sensor open, 86
compensation sensor short, 87
encoder index not found, 89
fan failed, 88
flash lamp current overflow, 95
flash trigger lost, 96
FLF board not found, 92
flow cell removed, 99
lamp cover open, 91
leak, 82
leak sensor open, 84
leak sensor short, 85
motor encoder index wrong, 90
motor errors, 89
motor friction too high, 90
motor or encoder not found, 89
motor position not found or, 90
motor speed too low or unstable, 90
remote timeout, 80
shutdown, 79
synchronization lost, 81
time-out, 78
wavelength calibration failed, 97
wavelength calibration lost, 98
ESD (electrostatic discharge) strap, 132
exchanging. see repairs
excitation condenser, 243
excitation grating, 243
excitation monochromator, 246
excitation slit, 243
F
features
safety and maintenance, 329
firmware
