104 Chapter 5
Setting Measurement Conditions
Setting Fixed Frequency (CW Frequency)
Setting Fixed Frequency (CW Frequency)
Follow the steps below to specify a fixed frequency for the signal source when the sweep
parameter is any item other than frequency (i.e., oscillator level or dc bias).
Step 1. Press the
[Source] key to display the signal source menu.
Step 2. Press the
FREQUENCY key. This will display the current setting for the fixed frequency for
the segment in the parameter settings area in the upper-left part of the screen.
Step 3. Use the keys or the rotary knob in the ENTRY block in one of the following ways to
specify a value for the fixed frequency.
• Enter the desired value with the numeric keys (
[0] to [9], [.], and [-]) and then press one
of the unit keys (
[G/n], [M/m], [k/m], or [´1]).
• Turn the rotary knob (
m
mm
m) until the desired value is set.
• Press the step keys ([][¯]) to set the desired value.
To Next Page
