Chapter 8 269
Analysis and Processing of Result
Specify partial search range
8. Analysis and Processing
of Result
When the sweep type is list sweep:
Step 1. Activate the trace in which you want to specify a partial search range.
Step 2. Press the
[Search] key to display the Search menu.
Step 3. Press the
SEARCH RANGE MENU key to display the Search Range menu.
Step 4. Specify the partial search range by the following key operations:
Step 5. Press the
SEGMENT NUMBER key if the partial search range was specified as one specific
segment in the previous step. The set number of the current partial search segment number
is displayed in the set parameter value field in the upper left area of the screen.
Step 6. Use the keys or rotary knob of the ENTRY block in one of the following ways to specify
the partial search segment number.
• Enter the desired value with the numeric keys (
[0] to [9]) and then press the unit key
[´1].
• Turn the rotary knob (
m
mm
m) until the desired value is set.
• Press the step keys ([][¯]) to set the desired value.
NOTE There is no key to turn on or off the partial search range in list sweep. Use the partial search
function for the segment number specified by selecting the
SEGMENT key.
Press the
RNG LINE on OFF key located in the Search Range menu to change the soft label
to
RNG LINE ON off. This will display the partial search range boundary line in the list
sweep. When the measurement parameter is COMPLEX Z-Y, however, the boundary line
is not displayed.
Active Trace Key operation
Trace A
[A]
Trace B [B]
Specify the partial search range Key operation
Full range of list sweep table
FULL
One specific segment of list sweep table
(specify the segment by the following steps)
SEGMENT
