324 Chapter 10
Specifications and Supplemental Performance Characteristics
Basic Characteristics
Specifications describe the instrument's warranted performance over the temperature range
of 0°C to 40°C (except as noted). Supplemental performance characteristics are intended to
provide information that is useful for applying non-warranted performance parameters to
the instrument. Such parameters are denoted as SPC (supplemental performance
characteristics), typical, or nominal. Warm-up time must at least 30 minutes after power-on
for all specifications.
Basic Characteristics
Measurement Parameter
Measurement Terminal
Source Characteristics
Frequency
Voltage Signal Level
Impedance Parameters |Z|-q, R-X, Ls-Rs, Ls-Q, Cs-Rs, Cs-Q, Cs-D, |Y|-q,
G-B, Lp-G, Lp-Q, Cp-G, Cp-Q, Cp-D, Complex Z-Y,
|Z|-Ls, |Z|-Cs, |Z|-Lp, |Z|-Cp, |Z|-Rs, |Z|-Q, |Z|-D,
Lp-Rp, Cp-Rp
Configuration Four-terminal pair configuration
Connector type Four BNC (female) connectors. Can be converted to
one-port terminal using the 42942A Terminal Adapter
(7-mm port) or the 42941A Impedance Probe
(3.5-mm port).
Range 40 Hz to 110 MHz
Resolution 1 mHz
Accuracy
without Option 1D5 ± 20 ppm (at 23 ± 5°C)
± 40 ppm (at 0 to 55°C)
with Option 1D5 ± 0.13 ppm (at 0 to 55°C)
Range 5 mVrms to 1 Vrms
Resolution 1 mV
Accuracy
