Chapter 10 349
Specifications and Supplemental Performance Characteristics
General Characteristics
10. Specifications and
Supplemental Performance
Characteristics
General Characteristics
External Reference Input
Internal Reference Output
High Stability Frequency Reference Output (Option 1D5)
External Trigger Input
Frequency 10 MHz ± 10 ppm (typical)
Level - 5 dBm to + 5 dBm (typical)
Input impedance 50 W (nominal)
Connector type BNC (female)
Frequency 10 MHz (nominal)
Level 0 dBm (typical)
Output impedance 50 W (nominal)
Connector type BNC (female)
Frequency 10 MHz (nominal)
Level 0 dBm (typical)
Output impedance 50 W (nominal)
Connector type BNC (female)
Level TTL
Pulse width (Tp) ³ 2 ms (typical), see Figure 10-9 for the definition of
Tp.
Polarity Positive or Negative (selectable)
Connector type BNC (female)
