214 Chapter 8
Analysis and Processing of Result
Listing data at several points on the trace
Listing data at several points on the trace
When the main marker (marker numbered 0) is used, data on the trace (sweep parameter
value and measured value) are always displayed in the Marker Sweep Parameter Value and
Marker Measurement Parameter Value fields in the right area of the screen. To display data
at several points on the trace at one time, use the sub-markers (markers numbered 1 to 7)
and the marker list function.
Displaying several marker positions using softkey labels
When you turn on the sub-marker, the softkey label of the sub-marker in the Sub-Marker
Setting menu changes to the sweep parameter value and measurement parameter value at
that point.
Step 1. Activate the trace that you want to read (to which the setting is applied).
Step 2. Use the softkeys displayed by pressing the
[Marker] key or the [Search] key, the keys in
the
ENTRY block, and so on, to move the main marker to one of the points on the trace
whose data you want to read.
Step 3. Press the
[Marker] key to display the Marker menu.
Step 4. Press the SUB MKR key to display the Sub-Marker Setting menu.
Step 5. Select one of the following sub-markers to place it at the current main marker position.
When you press the softkey, the sub-marker appears at the current main marker position,
and the display of the softkey labels change from OFF to the sweep parameter value and
measurement parameter value, which indicate the position of the sub-marker.
Step 6. Repeat Step 2 through Step 5 to place sub-markers at several points on the trace.
Active trace Key operation
Trace A
[A]
Trace B [B]
Type of sub-marker Key operation
Sub-marker 1 (marker number 1) 1 OFF
Sub-marker 2 (marker number 2) 2 OFF
Sub-marker 3 (marker number 3) 3 OFF
Sub-marker 4 (marker number 4) 4 OFF
Sub-marker 5 (marker number 5) 5 OFF
Sub-marker 6 (marker number 6) 6 OFF
Sub-marker 7 (marker number 7) 7 OFF
