Agilent Technologies 4294A User Manual

Appendix B 421
Key Definitions
Softkeys displayed by pressing the [Save] key
B. Key Definitions
Softkeys displayed by pressing the [Save] key
Table B-105 Save (Save) menu
Key operation: [Save]
Softkey Function GPIB command
STATE ä Selects storage of the configuration states and internal data array of the Agilent
4294A and displays Table B-106, “Filename entry (File Name) menu,” on
page 421.
SAVDSTA <string>
DATA ä
Selects storage of the internal data array of the Agilent
4294A and displays
Table B-107, “Data save (Save Data) menu,” on page 422.
(N/A)
GRAPHICS ä Selects storage of the displayed screen in TIFF format and displays Table B-106,
“Filename entry (File Name) menu,” on page 421. It is stored in the colors
selected in Table B-99, “Copy configuration (Copy Setup) menu (1/2),” on page
417. The softkeys are also stored.
SAVDTIF <string>
TOUCHSTONE Selects storage of the internal data array in the touchstone format and displays
Table B-107, “Data save (Save Data) menu,” on page 422.
SAVDS1P <string>
RE-SAVE FILE ä Displays Table B-111, “File selection (Select File) menu,” on page 424. RESAVD <string>
POWER ON CONFIG ä Displays Table B-109, “Power-on configuration save (Save config?) menu,” on
page 423.
SAVPSTA
FILE UTILITIES ä Displays Table B-110, “File utility (File Utility) menu,” on page 423. (N/A)
STORE DEV [ ] ä Displays Table B-81, “Mass storage (Store Device) menu,” on page 408. In [ ]
of the softkey label, the currently selected mass storage is displayed (flexible
disk drive: [FLOPPY], volatile memory disk: [MEMORY], or nonvolatile
memory disk (flash memory): [FLASH]).
(N/A)
Table B-106 Filename entry (File Name) menu
Key operation: [Save] - STATE
[Save] - DATA - BINARY/ASCII
[Save] - GRAPHICS
[Save] - FILE UTILITIES - CREATE DIRECTORY
Softkey Function GPIB command
SELECT LETTER Enters a character indicated by “” on the screen. (N/A)
SPACE Enters a space. (N/A)
BACK SPACE Deletes a character last entered. (N/A)
CLEAR NAME Deletes all entered characters. (N/A)
STORE DEV [ ] ä Displays Table B-81, “Mass storage (Store Device) menu,” on page 408. In [ ]
of the softkey label, the currently selected mass storage is displayed (flexible
disk drive: [FLOPPY], volatile memory disk: [MEMORY], or nonvolatile
memory disk (flash memory): [FLASH]).
(N/A)
