34 Chapter 2
Learning Operation Basics
Specifying Measurement Conditions
Step 2. Press the LOG key to select Log (logarithmic) sweep.
Set the Sweep Start Value to 100 Hz
Step 1. Press the [Start] key. The current setting of the sweep start value appears in the Parameter
Setting field in the upper-left area of the screen.
Step 2. Type “100” into the Parameter Setting field using these ENTRY block keys:
[1][0][0].
Step 3. Specify that the value does not take any unit by pressing the
[´1] key in the ENTRY block.
This puts your entry into effect.
Set the Sweep Stop Value to 100 MHz
Step 1. Press the [Stop] key. The current setting of the sweep stop value appears in the
Measurement Parameter field in the upper-left area of the screen.
Step 2. Type “100” into the Parameter Setting field using these ENTRY block keys:
[1][0][0].
Step 3. Suffix your entry with “M” (mega) by pressing the
[M/m] key in the ENTRY block. This
puts your entry into effect.
Set the Measurement Bandwidth to 2
Step 1. Press the [Bw/Avg] key to display the Measurement Bandwidth/Averaging menu.
Step 2. Press the
BANDWIDTH [ ] key to display the Measurement Bandwidth Setting menu.
Step 3. Set the measurement bandwidth to 2 by pressing the
2 key.
