Chapter 8 225
Analysis and Processing of Result
Search the point of target measurement
8. Analysis and Processing
of Result
Search the point of target measurement
You can use the target value search function to move the main marker in automatic mode to
the point of the specified (target) measurement on the trace and to read the sweep
parameter value at that point.
Step 1. Activate the trace to be searched.
Step 2. Press the
[Search] key to display the Search menu. If the main marker is not on the active
trace, the main marker appears at the position of the sweep center value on the trace.
Step 3. Press the
TARGET key, which displays the current target value in the set parameter value
field in the upper left area of the screen. At the same time, the target menu also appears.
NOTE When the TARGET key is pressed, the target value search is carried out based on the preset
target value (zero when preset), and the main marker is moved to the point of the target
measurement. Accordingly, once the target value is set, the set target value can be searched
only by pressing the TARGET key except when the Preset key is pressed.
Step 4. Use the keys or rotary knob of the ENTRY block in one of the following ways to specify a
new target value.
• Enter the desired value with the numeric keys (
[0] to [9] [.] and [-]) and then press one
of the unit keys (
[G/n], [M/m], [k/m], or [´1]).
• Turn the rotary knob (m
mm
m) until the desired value is set.
• Press the step keys ([][¯]) to set the desired value.
When the value is set, the target value is searched and the main marker moves to the target
value.
Active trace Key operation
Trace A
[A]
Trace B [B]
