Agilent Technologies 4294A User Manual

314 Chapter 9
Setting/Using Control and Management Functions
Setting/Checking the LAN
Setting/Checking the LAN
This section describes how to set or check the addresses necessary to use the Agilent
4294A's LAN (Local Area Network) functions. For more information on the use of the
LAN, refer to the Programming Manual.
Setting/Checking the IP Address
Follow these steps to set or check the IP (Internet Protocol) address. The IP address is
delimited into four parts by periods; each part is independently set.
Step 1. Press the
[Local] key to display the Local menu.
Step 2. Press the
IP ADDRESS key to display the IP Address Setting menu.
Step 3. Press the 1st key. In the set parameter value field in the upper left area of the screen, the 1st
part of the IP address (current set value) is displayed. Below it, the entire currently set IP
address is displayed in a smaller size.
Step 4. Use the keys or rotary knob of the ENTRY block in one of the following ways to specify
the 1st part of the IP address.
• Enter the desired value with the numeric keys (
[0] to [9]) and then press the [´1] unit
key.
• Turn the rotary knob (
m
mm
m) until the desired value is set.
• Press the step keys ([][¯]) to set the desired value.
The 1st part of the IP address can be set to an integer ranging from 0 through 255.
Step 5. Press the
2nd key. In the set parameter value field in the upper left area of the screen, the
2nd part of the IP address (current set value) is displayed. Below it, the entire currently set
IP address is displayed in a smaller size.
Step 6. Use the keys or rotary knob of the ENTRY block in one of the following ways to specify
the 2nd part of the IP address.
• Enter the desired value with the numeric keys (
[0] to [9]) and then press the [´1] unit
key.
• Turn the rotary knob (
m
mm
m) until the desired value is set.
• Press the step keys ([][¯]) to set the desired value.
The 2nd part of the IP address can be set to an integer ranging from 0 through 255.
Step 7. Press the
3rd key. In the set parameter value field in the upper left area of the screen, the
3rd part of the IP address (current set value) is displayed. Below it, the entire currently set
IP address is displayed in a smaller size.
Step 8. Use the keys or rotary knob of the ENTRY block in one of the following ways to specify
the 3rd part of the IP address.
• Enter the desired value with the numeric keys (
[0] to [9]) and then press the [´1] unit
key.
