344 Chapter 10
Specifications and Supplemental Performance Characteristics
Basic Characteristics
Display Functions
Marker Functions
Display
Size/Type 8.4 inch color LCD (TFT)
Resolution (pixels) 640 ´ 480 (VGA)
Scale types
X-axis scale Linear and log
Y-axis scale Linear and log (depending on sweep type)
Number of traces
Data trace 2 traces (trace A and trace B)
Memory trace 2 traces (trace A and trace B)
Split display Available (trace A: upper half, trace B: lower half)
Instrument/IBASIC display
selection
All instrument, Half instrument and half IBASIC, All
IBASIC, or Instrument and IBASIC status.
Other display functions Inactive trace off, trace accumulation, phase
expansion
Data math functions
Data - memory, data/memory
1
, delta%
2
, offset
1. Complex Z-Y measurements only.
2. Except for Complex Z-Y measurements.
Marker type and number
Main marker One for each trace (A and B).
Sub marker Seven for each trace (A and B).
D marker One for each trace (A and B).
Marker search
Search type Maximum, minimum, target, peak, trace bandwidth
analysis
Search track Performs search with each sweep
Marker X-axis display Sweep parameter value, sweep elapsed time, or
relaxation time (1/2pf)
Other functions Marker continuous mode, D marker mode, marker
coupled mode, marker value substitution (marker®),
marker zooming, marker list, marker statistics,
marker signal/dc bias monitor
