160 Chapter 7
Setting Up the Display of Measurement Results
Selecting the Graph Axis Format
Selecting the Graph Axis Format
When Using Cartesian Coordinates
Unless the Agilent 4294A is configured to perform a COMPLEX Z-Y measurement
(complex impedance for Trace A, complex admittance for Trace B), it displays
measurement results in a Cartesian-coordinate graph whose horizontal and vertical axes
indicate the sweep and measurement parameter values, respectively. Use the following
procedure to select the vertical axis format for a Cartesian-coordinate graph:
Step 1. Activate the trace for which you want to set the axis format.
Step 2. Press the
[Format] key to display the Format menu.
Step 3. Select the desired vertical axis format by pressing the appropriate key:
NOTE The horizontal axis format is automatically determined based on the selected sweep type.
To activate: Press:
Trace A
[A]
Trace B [B]
To sele ct: Press :
Linear
LIN
Logarithmic LOG
