Agilent Technologies 4294A User Manual

158 Chapter 7
Setting Up the Display of Measurement Results
Selecting the Measurement Parameters
Selecting the Measurement Parameters
Step 1. Press the [Meas] key to display the Measurement Parameter menu.
Step 2. Select the measurement parameter for each trace with a keystroke shown in Table 7-1.
Table 7-1 Selecting the Measurement Parameters
To selec t:
Press:
Trace A Trace B
Absolute impedance value Impedance phase
|Z|-q
Equivalent series resistance Equivalent series reactance R-X
Equivalent series inductance Equivalent series resistance Ls-Rs
Equivalent series inductance
Q value
1
1. Quality factor.
Ls-Q
Equivalent series capacitance Equivalent series resistance Cs-Rs
Equivalent series capacitance
Q value
1
Cs-Q
Equivalent series capacitance Dissipation factor Cs-D
Absolute admittance Admittance phase more 1/3 - |Y|-q
Equivalent parallel conductance Equivalent parallel susceptance more 1/3 - G-B
Equivalent parallel inductance Equivalent parallel conductance more 1/3 - Lp-G
Equivalent parallel inductance
Q value
1
more 1/3 - Lp-Q
Equivalent parallel capacitance Equivalent parallel conductance more 1/3 - Cp-G
Equivalent parallel capacitance
Q value
1
more 1/3 - Cp-Q
Equivalent parallel capacitance Dissipation factor more 1/3 - Cp-D
Impedance (complex value) Admittance (complex value) more 1/3 - more 2/3 - COMPLEX Z-Y
Absolute impedance value Equivalent series inductance more 1/3 - more 2/3 - |Z|-Ls
Absolute impedance value Equivalent series capacitance more 1/3 - more 2/3 - |Z|-Cs
Absolute impedance value Equivalent parallel inductance more 1/3 - more 2/3 - |Z|-Lp
Absolute impedance value Equivalent parallel capacitance more 1/3 - more 2/3 - |Z|-Cp
Absolute impedance value Equivalent series resistance more 1/3 - more 2/3 - other - |Z|-Rs
Absolute impedance value
Q value
1
more 1/3 - more 2/3 - other - |Z|-Q
Absolute impedance value Dissipation factor more 1/3 - more 2/3 - other - |Z|-D
Equivalent parallel inductance Equivalent parallel resistance more 1/3 - more 2/3 - other - Lp-Rp
Equivalent parallel capacitance Equivalent parallel resistance more 1/3 - more 2/3 - other - Cp-Rp
