156 Chapter 6
Calibration
Selecting Calibration/Compensation Data Points
List of fixed calibration/compensation frequency points
When the fixed frequency points for user calibration and fixture compensation are selected
(softkey label:
COMP POINT [FIXED]), calibration/compensation is performed at the
frequency points listed in Table 6-2.
NOTE The same frequency points are shown in different positions in Table 6-2 because
calibration/compensation is performed at some frequency points depending on the different
internal setups used with the Agilent 4294A.
Table 6-2 Fixed Calibration/Compensation Points (100 points, in Hz)
40, 45, 55, 70, 91,
130, 195, 320, 600,
1k, 2.1k, 4k, 9.5k,
21k, 40k, 96k,
130k, 170k, 230k, 275k, 320k, 400k, 510k, 630k, 750k, 800k, 900k,
1M, 1.1M, 1.1M, 1.6M, 1.9M, 2.3M, 2.6M, 3M, 3M, 3.4M, 3.8M, 4.2M, 4.6M, 5M, 5M,
6M, 7M, 8.5M,
10M, 11.5M, 13M, 14M, 15M, 15M, 16M, 18M, 20M, 20M, 22M, 24M, 26M, 28M, 30M,
32M, 34M, 36M, 38M, 40M, 42M, 44M, 46M, 48M, 50M, 52M, 54M, 56M, 58M, 60M,
62M, 64M, 66M, 68M, 70M, 72M, 74M, 76M, 78M, 79.9M, 82M, 84M, 86M, 88M, 90M,
92M, 94M, 96M, 98M,
100M, 102M, 104M, 106M, 108M, 110M
